Overview
The Robopac Ecoplat Plus is a reliable and cost-effective semi-automatic turntable stretch wrapping machine designed for palletized loads. As an entry-level solution from Robopac, the Ecoplat Plus offers a perfect balance between performance, simplicity, and affordability.
Built with robust components and Italian engineering, this machine ensures consistent wrapping quality, improved load stability, and reduced film consumption. It is ideal for small to medium-sized businesses looking to optimize their end-of-line packaging operations without heavy investment.
Key Features & Benefits
1. Reliable & Sturdy Construction
- Designed following strict European quality and safety standards
- Long-lasting components ensure stable performance over time
- Suitable for continuous industrial use
2. User-Friendly Operation
- Simple control panel for easy operation
- Basic version: electromechanical buttons
- FRD version: LED display with parameter selector (JOG system)
3. Flexible Wrapping Cycles
- Adjustable parameters:
- Turntable rotation speed
- Film carriage up/down speed
- Top and bottom wraps
- Automatic load height detection via photocell
4. FRD Film Carriage (Mechanical Brake)
- Manual film tension adjustment
- Brake engagement/release system for easy film attachment
- Ensures stable load containment with reduced film waste
5. Compact & Space-Saving Design
- Small footprint – ideal for limited warehouse space
- Easy installation and relocation
- Forklift accessible from front and rear
6. Industry 4.0 Ready (Optional)
- Compatible with R-Connect system
- Remote monitoring and maintenance support
- Improves machine uptime and efficiency
7. Low Investment – High Efficiency
Ideal entry-level pallet wrapper
Reduces labor cost and packaging time
Optimizes film usage and improves load protection
Available Versions
The Robopac Ecoplat Plus is available in multiple configurations to meet different operational needs, from basic pallet wrapping to more controlled and efficient packaging processes.
1. Ecoplat Plus Base (Entry-Level Version)
The Ecoplat Plus Base is designed for businesses looking for a simple, reliable, and cost-effective pallet wrapping solution.
- Equipped with an electromechanical control panel using push buttons
- Ideal for operators with minimal technical experience
- Allows manual adjustment of key parameters such as: Turntable rotation; Film carriage movement (up/down)
- Includes automatic wrapping cycle with photocell for load height detection
- Perfect for low-volume operations or facilities starting to automate packaging
This version focuses on simplicity, durability, and affordability, making it a great entry point into automated pallet wrapping.
2. Ecoplat Plus FRD (Advanced Control Version)
The Ecoplat Plus FRD offers enhanced functionality and better control over the wrapping process, suitable for more demanding environments.
- Features a digital control panel with LED display and JOG selector
- Enables precise adjustment of: Turntable speed; Film carriage speed; Top and bottom wraps; Wrapping cycles (up & down, top sheet, reinforcement wraps)
- Equipped with FRD film carriage (mechanical brake system): Adjustable film tension for improved load containment; Easy film insertion and release system
- Allows operators to store and repeat wrapping settings, ensuring consistency
- Suitable for medium-volume production and diverse pallet types
This version delivers greater flexibility, improved wrapping quality, and better efficiency compared to the Base model.
3. Optional Upgrades & Customization
Both versions of the Ecoplat Plus can be enhanced with additional options to better fit specific operational requirements:
- Extended mast for higher pallet wrapping (up to 2400 mm or more)
- Larger turntable diameter (1650 mm) for bigger pallets
- Higher load capacity (up to 2000 kg)
- Ramp for pallet jack access
- Weighing scale integration
- R-Connect system (Industry 4.0) for remote monitoring and diagnostics
These options allow businesses to scale the machine according to production needs without upgrading to a higher model.
Technical Specifications (Ecoplat Plus)
| Specification | Details |
|---|---|
| Machine Type | Semi-automatic turntable stretch wrapper |
| Turntable Diameter | 1500 mm (standard) / 1650 mm (optional) |
| Max Load Weight | 1200 kg (standard) / up to 2000 kg (optional) |
| Turntable Speed | 4 – 10 rpm |
| Carriage Up/Down Speed | 1.4 – 4 m/min |
| Max Pallet Size (L x W) | 800 x 1200 mm (std) / 1000 x 1200 mm (opt) |
| Max Wrapping Height | 2200 mm (std) / 2400 mm (opt) |
| Film Carriage Type | FRD (mechanical brake) |
| Film Stretch | Manual |
| Power Supply | 230V, 1Ph, 50/60Hz |
| Installed Power | Approx. 1.2 kW |
| Max Reel Dimensions | 500 x 300 mm |
| Max Reel Weight | 20 kg |
| Film Thickness | 17 – 35 µm |
Why Choose Robopac Ecoplat Plus?
- Trusted Robopac quality with affordable investment
- Easy to use, maintain, and integrate
- Flexible for various pallet sizes and industries
- Improves packaging efficiency and reduces material waste
- Upgrade-ready with Industry 4.0 technology
Conclusion
The Robopac Ecoplat Plus is a smart choice for businesses seeking a dependable and cost-efficient pallet wrapping solution. With its user-friendly design, robust construction, and flexible functionality, it delivers consistent performance while optimizing packaging operations.
Looking for genuine Robopac Ecoplat Plus in Vietnam? MNB provides 100% authentic Robopac machines, expert consultation, installation, and after-sales support.
👉 Contact us today for pricing and technical advice.
